Брой на предишни собственици
0
Максимален капацитет на повдигане
2 000 кг
Тип каросерия
Фиксирана рамка
Вид кабина
Затворена кабина
Ниво на емисии
Етап IIIA / Ниво IV междинен
Капацитет на кофата
0,50 m3
Производител на двигателя
Kubota
Максимална скорост
30 kм/ч
Предни гуми/ остатъчни шаси
100
Страна на производство
САЩ
Условия за доставка
CIF, EXW
Аксесоари
Система за управление на машината
Система за гасене на пожар
Ъглово движение на скобата за закрепване
Отчитане на натоварването
Друга информация
Basic performance
Rated loading capacity (kg):
nine hundred and eighty-nine
Overturning load (kg):
one thousand nine hundred and seventy-eight
Whole machine weight (kg):
three thousand four hundred and ninety-six
Form of lifting mechanism:
Radial lifting
Bucket digging force (N):
nineteen thousand three hundred and thirty-five
Arm lifting force (N):
seventeen thousand seven hundred and seventy-seven
Rated loading capacity (m3):
engine
Engine model:
Kubota/V3307-DI-TE3 Kubota
Rated power (kw/rpm):
fifty-five point four
Maximum torque (N.m/rpm):
264.4/1600
Displacement (L):
three point three
Number of cylinders:
four
Emission standards:
Interim Tier IV
Through performance
Drive motor form:
Maximum torque output of drive motor (N.m/cc):
Maximum driving speed (km/h):
11.4/19.8 (optional)
Tire size:
12×16.5
Front turning radius (with bucket) (mm):
two thousand one hundred and nineteen
Front turning radius (without attachments) (mm):
Rear turning radius (mm):
one thousand six hundred and ninety-three
Departure angle (°):
twenty-five point two
hydraulic system
Main pump type:
gear pump
System safety pressure (bar):
two hundred and forty-one
Rated flow rate of the system (L/min):
87.1/115.5 (high traffic configuration, optional)
Lifting time (s):
Unloading time (s):
Placement time (s):
Three items and (s):
Oil capacity
Fuel tank (L):
one hundred and three point three
Hydraulic oil tank (L):
ten point two
Hydraulic system (L):
forty-one point six
Engine coolant (L):
eleven point four
Crankcase (L):
eleven point four
Chain wheel oil tank (L):
Scope of work
Maximum working height (mm):
Maximum unloading height (mm):
two thousand three hundred and sixty-seven
Unloading distance (at maximum height) (mm):
five hundred and forty-four
Maximum height of bucket hinge pin (mm):
three thousand and seventy-three
Unloading angle at maximum unloading height (°):
forty-two point four
The highest bucket angle of the bucket (°):
ninety-six point nine
Bucket retraction angle on the ground (°):
thirty
Whole machine specifications
Total length (without attachments) (mm):
two thousand seven hundred and fifty-four
Total length (with bucket) (mm):
three thousand four hundred and seventy-four
Full width (tire edge) (mm):
one thousand eight hundred and thirty-two
Full width (bucket edge) (mm):
1727/1880
Full height (up to the top of the cab) (mm):
two thousand and sixty-five
Wheelbase (mm):
one thousand one hundred and fifty
Track width (mm):
one thousand five hundred and seven
Minimum ground clearance (mm):
two hundred and sevenПокажете повече
