Максимална височина на повдигане
3 900 cм
Максимален капацитет на повдигане
12 000 кг
Брой на вътрешния инвентар
AITC005
Ниво на емисии
Етап IIIA / Ниво III
Оригинален цвят
Orange and red
Производител на двигателя
Yuchai YCDV4863-235
Размери на транспортиращото тегло
1162025003.025 m
Страна на производство
Китай
Условия за доставка
FOB, CIF
Друга информация
Applicable working conditions：Housing construction,Demolition works
Excellent performance
Maximum lifting height of main arm: 39m
Maximum lifting weight of fully extended arm: 4.4t
Maximum lifting torque: 598kN.m
The cross-section of arm, frame and outrigger is fully upgradedStrength performance and torsion resistance maintain the leading level in the industry
Maximum lifting height
39m
Maximum lifting moment
598kN·m
Maximum lifting capacity
12t
Ingenious power
i-ECO sensorless regeneration technology No parking regeneration is required for long-term operation, reducing fuel consumption Upgraded engine + 8-speed Fast (with synchronizer) Smooth gear shifting and stronger power
Leading control
110m/r large displacement 9-piston oil pump + load-sensing system + pilot control, better combined action performance and controllability Pressure adaptive telescopic technology Upgraded boom telescopic stability, smooth telescopic start and stop
Comfortable evolution
Newly upgraded classic 311 cab, optional sleeper 25-ton Shenzhou control cab, large space for better driving experience
Performance parameters
Maximum lifting height
39m
Maximum lifting moment
598kN·m
Maximum lifting capacity
12t
Speed Parameters
Maximum single rope speed of main winch
130m/min
Boom full extension/retraction time
45/40s
Full lifting/lowering time of crane arm
35/60s
Maximum rotation speed
2.5r/min
Weight parameters
Total weight
19200kg
Maximum weight
2t
Size parameters
Machine length
11620mm
Full width
2500mm
Overall height
3250mm
Outrigger span (horizontal x vertical)
6.2×5.15m
Power parameters
Engine Model
Yuchai YCDV4863-235
Maximum engine power
173/2300kW/rpm
Maximum engine output torque
860/（1200-1700）N·m/rpm
Driving parameters
Maximum driving speed
90km/h
Minimum turning radius
9m
Maximum climbing grade
45%
Approach Angle
13°
Departure angle
13°Покажете повече
